Female Cat6 Rj45 Jack 24.10 Mm 1000v Ac Rms 50hz 1 Min Dielectric Resistance
Female Cat6 Rj45 Jack 24.10 Mm 1000v Ac Rms 50hz 1 Min Dielectric Resistance
Contact Now

Female Cat6 Rj45 Jack 24.10 Mm 1000v Ac Rms 50hz 1 Min Dielectric Resistance

Minimum Order Quantity : 1 piece Price : Please contact us to get the latest price
Packaging Details : Tray in Carton Delivery Time : 10 days
Payment Terms : L/C, T/T, Western Union, MoneyGram Supply Ability : 100K pcs/day
Place of Origin: Guangdong of China Brand Name: TM
Certification: UL,Rohs,Reach,ISO9001 Model Number: TMZJ014058

Detail Information
Jack Type: RJ45 Number Of Positions: 8
Terminals Per Port: 8 LED Option: No
Shielded EMI Tabs: No Voltage Rating: 125 V
Current Rating: 1.5 A Contact Resistance: 30mΩ
Insulation Resistance: 500 MΩ MIN @ 500V DC Dielectric Resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN Minimal Order: 1pcs
Manner Of Packing: Tray In Carton Delivery Time: 20 Days
Supply Ability: 5KK/year
High Light:

cat6 shielded jack

,

modular jack cat 6

Product Description

Industrial Cat6 RJ45 Female connector All materials mates with modular plug Length 24.10 mm TMZJ014058





Tian Mu satisfies costomers demand to the maximum extant for the purpose of sustainable operation. meet customer demand with clients to achieve win-win results.Forecast future, The company will continue insists on the theory of "take the talented person as a fundamental, take the market as the guaidnce,take the quality as the guarantee,take the survice as an objective "Create enterprise-class communications.



We will embrace change and make constant innovations create the glorious future with the all customer.



RJ45 Without Transformer (TMZJ014058) Attributes:

Model: TMZJ014058
Place of Origin: Guangdong of China
Certification: UL,Rohs,Reach,ISO9001
Product Type : RJ45 Modular Connector
Jack Type: RJ45
Number of Positions : 8
Terminals per Port: 8
LED Option: No
Shielded EMI Tabs: No
Voltage rating: 125 V
Current rating: 1.5 A
Contact resistance: 30mΩ
Insulation resistance: 500 MΩ MIN @ 500V DC
Dielectric resistance: 1000V AC RMS 50Hz. 1MIN
Durrability: 750 CYCLES MIN
Minimal Order: 1pcs
Manner of packing : Tray
Delivery Time: 20 Days
Supply Ability: 5KK/year



RJ45 Female Connector (TMZJ014058) Mechnical Drawing:

 Female Cat6 Rj45 Jack 24.10 Mm 1000v Ac Rms 50hz 1 Min Dielectric Resistance 0
